AIS

AIS RECEIVER Model FA-30

For Recreational Boats For Fishing Vessels

The FA-30 delivers "Real-Time" AIS information to navigation systems providing critical collision avoidance information in all weather conditions

Acquisition and tracking of traffic around your vessel is absolutely necessary for safe and efficient navigation. FURUNO’s FA-30 AIS Receiver provides navigational data about other AIS-equipped vessels, increasing your situational awareness and allowing you to navigate more safely.

NavNet Connect Black Box Ethernet Plug & Play

Features

  • Enhances safe navigation by receiving critical navigation information from local AIS-equipped vessels

  • Vastly improves situational awareness in any weather conditions including dense fog, darkness, and congested waterways

  • Dual parallel channel, "Full Duplex" receiver design receives AIS contact messages up to 100% more often than dual channel "Multiplexing" receivers

  • High sensitivity, synthesized receiver automatically switches between international and local AIS channels

  • Optional amplified VHF splitter allows the use of a single antenna for VHF radio and AIS Receiver

  • Network output to NavNet TZtouch2/TZtouch/3D for added redundancy and installation flexibility

  • Serial Output for integration with various radar and chart plotter systems

  • Bulkhead mounting and low power, flexible DC input voltage design for simplified installations

Specifications

GENERAL

TX/RX Frequency156.025 MHz to 162.025 MHz
Output Power
Channel Spacing25 kHz/12.5 kHz
Power Supply12-24 VDC, 1.2-0.6 A
Size90 (H) x 255 (W) x 219 (D)
Weight1.5 kg

Equipment List

Standard

  • MAIN UNIT FA-30-E
  • POWER/SERIAL COMBINED CABLE
  • STANDARD INSALLATION MATERIALS
  • SPARE PARTS

Option

  • WHIP ANTENNA W/BRACKET
  • LAN CABLE ASSY (CROSS)2 M
    10 M
  • VHF SPLITTER
  • LAN CABLE ASSY (CROSS)2 M

Interconnection Diagram

Connectable Products

Documentation

Contact

Locate a Distributor Contact a local distributor for further details.

* Specifications subject to change without notice.
