Continuing Evolution of Radar Technology

In order to safeguard ocean voyages, and the health and well-being of our environment, we have applied our technological expertise in Radar technology to various other useful applications.
In addition to delivering sophisticated Radar applications, such as Ice Radar and Oil Radar, and in order to detect specific material, Furuno is combining our sophisticated Radar technologies with other specialized equipment, so that more complex solutions can be developed, and many problems can be solved.

Next-Generation Solid-State Radars

Simplified maintenance with advanced target detection

Historically, ships at sea have been equipped with Radars that use magnetrons to generate radio waves. More recently, the global focus is on Solid State technology, Radars using solid elements such as semiconductors to generate radio waves. Furuno's development of Solid State technology and the initiation of its practical use has brought about even more unique features, with the promise to deliver even more useful and ground-breaking solutions.

Free from routine maintenance

Because a magnetron deteriorates with time and use, periodic replacement becomes necessary. The elements used in Solid State Radars do not deteriorate, and so the cost in parts and labor for maintenance over time is greatly reduced. For applications requiring continuous Radar operation, such as for large merchant ships and onshore monitoring stations, Solid State Radar provides the best solution to maintenance issues, and its use is expected to become even more prevalent in the future.

Solid-State Radars Antennas

Doppler Signal Processing

In Solid-State Radars, the clean, unmodulated signal can be processed using the principles of the Doppler effect, detecting any difference in frequency or wavelength. In this manner, Furuno Solid State Radars can perform advanced target detection that includes accurate information about the direction and velocity of moving targets.

Typical functions
  • Target Analyzer™ (Doppler Analysis)
    Any target approaching relative to the ship is considered potentially dangerous. Identification of this dangerous target is made instantly thanks to an automatic color shift of the target on the Radar screen.
  • Automatic Target Tracking
    Any target presenting a collision risk when approaching the ship is automatically acquired, and its predicted course and speed are displayed by vector (Marine Radar).
  • Detection of rain cloud movement
    The movement of rain clouds can be determined by detection of precipitation particles inside the cloud, and by assessing their speed (Weather Radar).
Video of the DRS4D-NXT Solid State Radar screen as displayed on the NavNet TZtouch 2

Bandwidth-friendly radio waves

Unlike the magnetron Radar, which requires variations in transmission frequency, Solid State Radar generates radio waves of a fixed frequency. Subsequently, the frequency band occupied is very small, contributing to efficient use of radio waves.

Solid-State Radar Example Images
  • Maintenance-free, next-generation Radar using Solid State elements for radio wave generation
  • Advanced target detection by Doppler signal processing utilizing phase information
  • Contributing to the efficient use of radio waves

Radars to fulfill a specific purpose: Ice path, Oil leak

Marine Radar applications to detect specific targets, such as cracks in the ice and spilled oil

Advancing the evolution of Navigation Radar through specialized signal processing

To meet a growing demand for the detection of specific objects, such as cracks in sea ice or oil slicks, we strive to make the best use of the technological potential of our Radars in order to display echoes in an easy-to-understand way.

Ice Radar

Find the cracks and navigate the best route

During a voyage in the North Pole, where the sea surface is covered with ice, icebreaker and ice-class vessels with high ice resistance are crucial. In order for these vessels to navigate safely and efficiently, it is important to find a route through the thinnest ice. This is how our Ice radar was born - a true Navigation Radar that makes ice cracks more visible than ever.

Ship sailing through ice

Principles of Ice Radar

According to the principle of refractivity, when they reach the surface of the unbroken ice, radio waves tend to be sent back towards the antenna which emitted the wave, and the reflected signal is weak. Conversely, when the ice is cracked and the surface non-uniform, radio waves will tend to be scattered, and the signal will appear stronger.
Furuno Ice Radar is designed to display with precision the echo of radio waves reflected from the broken parts of the ice, allowing quick and intuitive appraisal of the best possible routes. Simultaneously, Furuno's signal processing allows the same Radar to be used for Navigation.

Ice Radar Screen Shot

Introduction Video

Ice Radar

Oil Radar

Contribution to environmental protection

Oil Radar was developed with the aim of contributing to the protection of the environment and marine life by detecting oil spills on the sea surface.

Oil spills recovery

Principles of Oil Radar

The intensity of a reflected wave depends upon the height of the wave. Since oil is more viscous than sea water, a surface covered with oil makes it harder for that surface to properly reflect radio waves. As a result, Radar returns appear weaker. Furuno Oil Radars utilize a unique algorithm designed to display these areas in an easy-to-understand manner.
Surfaces covered by oil spills are identified and shown on the monitor automatically.

Oil Radar Screen Shot

Introduction Video

Oil Radar
  • Radar technology designed to meet specific demands, such as detection of cracked ice and oil spills
  • Ice Radar for safe and efficient navigation in icy waters
  • Oil Radar for quick oil detection and recovery at sea

Weather Observation Radars

Increase in demand for Weather Radars

As the world asks the question, "How can we better protect ourselves against localized weather phenomena, such as tornadoes and torrential rains?", it is with a great sense of urgency that we find and provide appropriate solutions to predict these phenomena. Furuno, using its expertise in the field of maritime technology, miniaturization, and solid state physics, has developed one of the world's most lightweight and compact Doppler Weather Radars ever.

Damage due to concentrated torrential rain (image)

World's smallest and lightest class Weather Radar

Unlike conventional, large-scale Weather Radars, FURUNO's compact Weather Radar can be installed in places considered too difficult to access, such as the roof of a tall building, or in mountainous areas.
By early detecting the raindrops inside a cumulonimbus, low level clouds that are too low for large-scale meteorological Radars scanning higher altitudes, we can build more efficient alert systems against torrential rains and tornadoes.

Compact and lightweight radar for optimal supplement of global surveillance weather Radars.

Detection of rain clouds and rainfall

Weather Radar transmits radio waves to determine the location of rain clouds, and the intensity of rainfall, by measuring the strength of the echo and the time it takes for a reflected wave to return.

Three-dimensional observation of rain clouds

Data measurement in three-dimensions

A Furuno Weather Radar rotates inside of a compact dome while transmitting, just like the Radar antennas installed on a ship. Unlike Marine Radar, however, each time a Furuno Weather Radar completes a 360-degree turn, the scanning angle increases so that a three-dimensional observation of the sky can be performed.

Inside a weather radar antenna

Dual Polarimetric Doppler Radar for accurate calculation of rainfall intensity

A single Polarimetric Doppler Weather Radar uses only horizontally polarized waves, while a Dual Polarimetric Radar employs both horizontal and vertical waves simultaneously. When using a Dual Polarimetric Doppler Radar, rain intensity can be calculated with greater accuracy.
This calculation can be performed by measuring the size of rain particles in both horizontal and vertical planes. Based on the current scientific knowledge, a raindrop tends to become horizontally distorted as it falls, as the influence of both gravity and atmosphere cause it to form into a long, ellipsoid droplet.

Measurement using dual polarization

Wind Gust detection with multiple Radars

Doppler Weather Radar has been developed for the purpose of preventing wind-related damage in areas frequently hit by strong winds and rain. Using the Doppler principle, along with a measurement of wind velocities with multiple radars, it is possible to monitor wind at sea with high spatiotemporal resolution. Because it is difficult to install an anemometer on site, the Doppler principle is utilized to effectively and accurately monitor wind at sea. In addition to displaying changes in wind speed and direction on the display, alarms and e-mail notifications can be sent so it is possible to effect a rapid response in the event of dangerous weather.

Measure indicating the wind direction of a wind cloud located 500 meters above the sky

Various applications

1. B-DASH Project*
B-DASH is a joint research project for more efficient rainwater management, with a focus on monitoring heavy rainfalls in urban areas. The experiment has been carried out in the Japanese cities of Fukui and Toyama, where a system composed of three Weather Radars has been utilized. This allows for the early detection of cumulonimbus, and more accurate observation.

* B-DASH Project : Breakthrough by Dynamic Approach in Sewage High Technology Project

In the Japanese cities of Fukui and Toyama, a Multi-radar system composed of 3 Radars has been installed

2. Wildfire observation in Australia
The FURUNO WR-2100 Weather Radar's small size allows it to be mounted on a transportable platform, creating a mobile observation unit that can be easily deployed to any desired location.

Observation vehicle equipped with weather radar
  • The world's smallest and lightest class of Doppler weather radar for enhanced weather prediction based on FURUNO's expertise in marine radars
  • Dual Polarization Doppler Radar accurately calculates rain intensity, thanks to an advanced measurement algorithm
  • Rain cloud observation in low elevation areas can fill in the gaps where larger Radars cannot reach

Surveillance Radars and Coastal Monitoring

Surveillance radar system for port monitoring

Furuno Radars are used in coastal surveillance system for coastal monitoring. Combined with AIS, cameras and alarm systems, they form a comprehensive system of complex surveillance systems, such as maritime traffic control, power station and farm surveillance, oceanic civil engineering, and other sensitive sites where security is a concern.

As a premiere marine equipment manufacturer, Furuno provides accurate target detection

By using a combination of advanced clutter removal functions and our vessel tracking technology, a more precise target tracking solution can be delivered. Moreover, by superimposing AIS and Radar information, different kinds of Radar operation from a single screen can be achieved. FURUNO has leveraged our expertise to support advanced monitoring tasks, such as functions to automatically generate a list of targets, and the enlargement/reduction of selected portions of the screen.

Screen shot of a monitoring terminal

Oil and Gas platforms

Comprehensive solution offering the best protection to the rig by preventing accidents with out-of-control Vessels, acts of piracy or terrorism and extreme weather conditions which represent major threats to the platform both in safety and maintenance cost.

Fish farms

For the safety of employees working on fish farms and particularly at night, for preventing acts of robbery, but also to monitor unknown vessels entering the area and potentially threatening lines and nets.

Ports and harbors

In ports, the main danger comes from a risk of collision between ships and the traffic needs to be constantly monitored to avoid such unfortunate and deadly accidents. A Safe berthing and an efficient transport of passengers and goods cannot be guaranteed without a reliable monitoring.

Marine protected areas

To protect the ecosystem and preserve its fragile balance, it is vital to be equipped to deal with illegal fishing and anchoring and to monitor these areas in an effective manner.

Waterside facilities

For the protection of coastal facilities and other critical areas that must be placed under strict surveillance to prevent acts of terrorism, to ensure the highest level of security and provide safety for the workers.

Introduction Video

  • Maritime transportation regulation and utilizing Radar to monitor offshore plants and sea farm
  • Accurate ship detection utilizing Furuno's expertise in Marine Radars
  • Comprehensive monitoring systems that combine various functions according to purpose
